Red Silicone Masking Cap

Red Silicone Masking Cap for Powder coating lines - send your drawing for a matched quote.

Material: Silicone
Temperature rating: Standard (unrated)
Color: Red
Reusable: Yes, multiple bake cycles

Part of the Rubber Bolt Protection Caps family.

Why choose· 01

Built for your duty.

Covers external threads and studs

Where a plug can't help, this cap protects protruding features.

Reusable friction fit

Snaps on and off cleanly across repeated coating cycles.

Standard cure-cycle rating

Confirmed against common bake and cure profiles.

Product details· 02

How it is made & specified.

This silicone masking cap covers a bolt, stud, or protruding thread during coating, protecting the mating surface from powder, paint or plating buildup. It is rated for standard bake and cure cycles without softening or losing its grip on the fastener.

Caps work where a plug alone cannot help - covering an external protrusion rather than sealing an internal bore. Match the internal cap diameter to the fastener or stud size for a snug friction fit; a loose cap can let coating material creep underneath during spray or dip application.

Like other silicone masking components, this cap is reusable across multiple coating cycles. It can be supplied loose in bulk or kitted alongside matching plugs and tape for a specific part number.

Specifications· 03

Red Silicone Masking Cap specification range.

Attribute	Value
Material	Silicone
Temperature rating	Standard (unrated)
Color	Red
Feature type	External bolt / stud / thread
Reusable	Yes

Match internal cap diameter to your fastener size for a snug friction fit.

Applications· 04

Where this product works.

Powder coatingPlatingE-coatingBolt and stud maskingExternal thread protection

Industry solution

Powder Coating

Recommended combinationView solution →

Industry solution

Plating

Recommended combinationView solution →

Materials & customization· 05

Materials & custom options.

Silicone

Send drawings for DFM review — we confirm materials, tolerances and feasibility before quoting.

Packaging & shipping· 05b

Export packing as standard.

Standard export packing on every order: inner bags keep molded parts and tape rolls clean and separated, cartons are rated for sea and air freight, and kits are counted and labeled per part number. Cleanroom-compatible sealed packaging is available for finish-critical work — request it at RFQ.

Full packaging & shipping details →

FAQ· 06

Red Silicone Masking Cap questions.

What's the difference between a masking cap and a masking plug?

A cap covers an external protrusion like a bolt or stud; a plug seals an internal hole or bore.

How do I size this cap correctly?

Match the cap's internal diameter to your fastener or stud size for a snug friction fit that won't let coating creep underneath.

Can this cap be reused?

Yes, it's designed for repeated coating cycles rather than single use.

Need red silicone masking cap? Send the spec.

Send your specification, drawing or process conditions. We reply with a technical quote, not a form letter.
